All in One Audio Video Conference Room System



The TV-UV200 ptz camera and M3-B Bluetooth speaker all in one video conference system, which included 3x optical zoom ptz camera, and Bluetooth speakerphone.

The camera equippedequipped with a 1/2.8" SONY CMOS sensor with 2.38 megapixels, can deliver high-definition 1080p@60fps videos with a wide field of view. Enjoy precise high-speed PTZ movement and experience smooth USB3.0 connection with NV-U series cameras.

TV-M3-B is a Bluetooth conference speakerphone with 360° omnidirectional voice pick up and can pick up 5 meters radius, USB plug and play. The all in one video conference system is better for small and huddle conference room.







Camera Model	TV-UV200
Sensor	1/2.8″SONY CMOS
Effective pixel	2.38 mega pixel
Video system	1080p@60/50/30/25fps, 720p@60/50/30/25fps
Zoom	3x optical zoom
Lens	f=2.38-7mm
Aperture	F1.96-3.64
Horizontal angle	103.69°(W)-42.12°(T)
Vertical angle	67.14°(W)-24.87°(T)
Diagonal angle	113.91°(W)-47.55°(T)
Video output	USB 3.0 (Wireless version available.)
Video resolution	1080P (1920 *1080) etc
Signal standard	NTSC/PAL
Preset position	User can set up to 255 presets (10 presets by IR remote)
Control terminal	RS-232, RS485
Shutter	1/30s～1/10000s, auto
Baud rate	38400/9600bps
Control protocol	VISCA, PELCO-D, PELCO-P(RS-232, RS485)
USB protocol	UVC1.1
Minimal Illumination	0.1Lux
SNR	≥50dB
Video encoding format	MJPEG, YUV
Horizontal rotation	350°(±175°)0.1°/s～100°/s
Vertical rotation	180° (±90°)0.1°/s～80°s
Power supply	DC 12V/2A
Power consumption	12W
Work temperature	0°~+50°
Work humidity	0~95% RH
Product size	247*165*170mm
Microphone model	TV-M3-B
Bluetooth	BT5.0
Battery	2400mAH(Built-in lithium battery) Music time (up to 8 hours ) Battery life(call) up to 6 hours. Charge time up to 3 hours
Connection Type	USB/Bluetooth/AUX
Meeting room size	15-30㎡
Meeting with	3-12 attendees
Pickup range	5 meters (16.4 feet)
Mics	2x Professional Mics Array
Microphone type	Omni-directional (360 degree pickup range)
Microphone sensitivity	-29dBFS
Noise reduction	Yes
Full duplex audio	Yes
AEC	Yes
Frequency Range	100Hz to 22kHz
Speaker	5W/95dB
Interface	1 x Type-C, 1 x 3.5mm audio port
System requirements	Windows 7/8/10 or above,MacOS 10.7 or above,Chrome OS V29.01547 or above





3x zoom all in one video conference system conference webcam with microphone and speaker can be used for colleague lecture, tele-medicine, living streaming, video conference, online learning and home video.





The TV-UV200 ptz camera and M3-B Bluetooth speaker all in one video conference system is compatible with most of the mainstream software such as Skype, Microsoft Teams, Google Meet, Cisco Webex, Zoom, BlueJeans, Amazon Chime, GoToMeeting, etc.



All-in-1 video and audio conferencing solution

The unique of TONGVEO conference room camera system, contains HD 1080p PTZ camera and Bluetooth conference speaker, All-in-one design brings professional video conferencing to any meeting space, the Bluetooth speakerphone and HD conference camera can simultaneously work normally,be seen, be heard and speaking at same time, used together to meet the conference video and audio very well, video conference system ideal for Small-to-medium conference rooms;







Full HD Video and Audio

3X optical zoom professional PTZ camera for conference rooms,Full Glass Lens,Adopt 1/2.8''SONY CMOS with 2.38 Mega pixel enhanced image sensor, provide 1920* 1080p high definition images and videos,supports horizontal rotation 350°,vertical rotation 180°, and 113° wide field of view with no video distortion,delivers brilliantly image resolution,While the full-duplex microphone array with echo cancellation picks up voices and delivers crystal-clear sound within a 16.4ft





Great & Smooth Conference Experience

This Bluetooth conference Speakerphone with microphone can help focus on the conference systems,pick up sound distance 5M(16.4ft),It adopts a hands-free microphone and hands-free speaker design, connected via USB, Bluetooth5.0, Dongle,no drivers need,built-in 2400mAh battery, long life can be 6-8 continuous work,it is suitable for a meeting room of 40 square meters and live meetings with 8-12 people;





Easy Setup video conferencing

Launch video meetings with a plug-and-play USB 2.0 connection to your laptop, desktop, computer, or Smart TV. and then you can start it immediately and run it on the video conferencing software,Anyone can easily set up this USB camera and control video conferencing or live streaming.widely used at video calls, video conferences, online courses, Tele-Medicine, remote training, remote interviews, etc





Ultra Compatibility 3 Years After-sale Warranty

This USB video conference camera and Bluetooth Conference Speaker works with most video conferencing apps including Zoom, Skype for Business, Polycom, Microsoft Lync, Cisco, WebEx, BlueJeans, Facebook Messenger, and more. Supports Windows 7, Windows 8.1, Windows 10, Mac OS 10.10 or higher. This video conference camera system comes with 3 years warranty, and we provide 30 days money back, any question will answer within 24 hours







Our certificate: CE, FCC, RoHS etc





Delivery:
For sample orders, we have products in stock; same day shipping when we get the order;
For purchase orders, we will ship within 3-7 working days;


Packaging:
Foam packaging inside; standard carton packaging outside.



What's in the box?

TV-UV200 ptz camera and M3-B Bluetooth speaker all in one video conference system included 3x zoom ptz camera and M3B Bluetooth microphone, and all related accessories.





Q: Where is your factory located?

A: In Shenzhen,China.

Q: Can you do OEM and ODM?

A: Yes, OEM and ODM are both acceptable. The basic quantity we will advise after we discuss.

Q: When can I get the price?
A: Usually we quote within 8 hours after we get your inquiry.

Q: What's your MOQ?

A: If we have the products in stock, it will be no MOQ. If we need to produce, we can discuss the MOQ according to customer's exact situation.

Q: What is the payment way?

A: 1)TT or Western Union for the trial order

2)ODM, OEM order, 30% for deposit,70% T/T before delivery.
