PTZ IP Conference Room Camera
20x optical zoom PTZ IP conference room camera;
With 1/2.8 HD CMOS sensor, 2.38 mega pixel resolution;
HDMI, SDI, USB, RJ45 4 video outputs;
FOV: 55.5 degree wide field of view;
Mic in audio output;
Preset position: 10 by IR remote controller and 64 by keyboard controller;
Description
Product introduction
The VC800 PTZ IP conference room camera is obtained with RJ45, HDMI, 3G-SDI, and USB2.0 video outputs, Adopts1/2.8'' CMOS HD CMOS with 2.38 megapixel and Full HD 1080p & 1080i output resolution, and a high dynamic image at 60 fps. It's suitable for a medium-sized conference room.

Product parameter
|
Model |
VC800 |
|
Sensor |
1/2.9 inch CMOS |
|
Effective pixel |
2.38 megapixel |
|
Video system |
1080p-30/25, 720p-30/25 |
|
Zoom |
20x optical zoom |
|
Lens |
f=5.5-110mm |
|
Aperture |
F1.6~3.5 |
|
Vertical angle |
58.6°(W)-3.6°(T) |
|
Diagonal |
60.2°(W)-3.7°(T) |
|
FOV |
55.5° |
|
Video output |
USB, HDMI, SDI, RJ45 |
|
Video resolution |
1080P (1920 *1080) etc |
|
Signal standard |
NTSC/PAL |
|
Preset position |
64 |
|
Control terminal |
RS-232, RS485 |
|
Shutter |
1/30s~1/10000s, auto |
|
Baud rate |
38400/9600bps |
|
Control protocol |
VISCA, PELCO-D, PELCO-P(RS-232, RS485) |
|
USB protocol |
UVC1.1 |
|
Minimal Illumination |
0.1Lux |
|
SNR |
≥50dB |
|
Video encoding format |
MJPEG, YUV |
|
Horizontal rotation |
350°(±175°)0.1°/s~100°/s |
|
Vertical rotation |
180°(±90°)0.1°/s~80°s |
|
Power supply |
DC 12V/2A |
|
Power consumption |
12W |
|
Work temperature |
0°~+50° |
|
Work humidity |
0~95% RH |
|
Product size |
247*165*170mm |
|
Product weight |
1.46kg/2.85kg(net / gross weight) |
Product feature and application
Unlock a world of possibilities with the IP Conference Room Camera. From video conferencing and online classes to live streaming, telemedicine, church services, and even digital court sessions, this camera is a versatile solution for a wide range of applications.


Production details
The 20x PTZ IP Conference Room Camera boasts a remarkable field of view at 55.5°. This camera stands as a versatile choice, featuring a multi-interface design.
A truly professional PTZ camera tailored for video conferencing and live streaming applications.

Experience a wide range of movement with a horizontal rotation angle spanning from -170° to +170°, coupled with a vertical rotation angle from -90° to +90°.

Compatible with both the keyboard controller and IR remote control, this camera offers seamless control options.
Easily preset up to 10 positions using the IR remote controller, and expand your options further to 64 positions via the keyboard controller.

The IR controller is highlighted by its user-friendly one-key flip function, making it incredibly convenient and easy to operate.

Featuring a multi-interface design, the camera comes equipped with RJ45, HDMI, SDI, and USB 4 video outputs, ensuring versatile connectivity options for your convenience.

The camera offers compatibility with various options such as ceiling, wall mount, and tripod setups, providing you with the flexibility to effortlessly capture precisely the images you envision.

Inside the box, you'll find an HD conference camera, a USB cable for seamless connectivity, a convenient wall mount for easy installation, an intuitive IR remote control for effortless operation, a power adapter to ensure uninterrupted power supply, a user's manual to guide you through setup and usage, and a set of screws for secure mounting.

Products Description
The VC800 Conference Room Camera is a revolutionary addition to your meeting space that redefines visual communication. With exceptional performance and versatile video output options, the VC800 is the ultimate choice for medium-sized conference rooms. From superior high-definition imagery to high frame rates and multiple connectivity methods, the VC800 is your perfect partner for seamless conference interactions.
1. Versatile Video Output Options: The VC800 offers four distinct video output options - RJ45, HDMI, 3G-SDI, and USB 2.0, catering to your diverse connectivity needs. Whether it's networking, high-definition displays, or other devices, the VC800 effortlessly adapts to ensure flexible and convenient conference setups.
2. Outstanding Visual Clarity and Frame Rate: Utilizing a 1/2.8-inch HD CMOS sensor with 2.38 megapixels, the VC800 delivers exquisite imagery in Full HD 1080p and 1080i output resolutions. Operating at an impressive 60 frames per second, the VC800 guarantees smooth visuals, capturing every frame with precision and finesse.
3. High Dynamic Imagery: With its exceptional dynamic image capabilities, the VC800 ensures vibrant and vivid visuals even in varying lighting conditions. Every subtle expression and gesture of your participants is accurately conveyed on-screen.
4. Tailored for Medium-Sized Conference Rooms: Designed with medium-sized conference rooms in mind, the VC800 takes spatial and visual requirements into consideration. Whether it's discussion or presentation, the VC800's comprehensive coverage and high-quality imagery meet your conference demands effectively.
5. Effortless Control and Preset Functionality: The VC800 is easily controlled through a remote, offering preset functionalities for swift transitions between different camera angles. Whether shifting focus or capturing panoramic views, the VC800 empowers you to effortlessly navigate conference dynamics.
The VC800 Conference Room Camera is the ideal choice for medium-sized conference rooms. Its diverse video output options, exceptional visual clarity, and high frame rates, along with precise preset controls, elevate your conference experience significantly. Whether it's business meetings, team collaborations, or remote training, the VC800 will be your ultimate collaborative partner.
